Ruijie Integration Guide

This guide walks you through the complete integration between a Ruijie / Reyee gateway and Useroam Cloud — captive portal authentication (WiFiDog external portal) and legal 5651 syslog forwarding.

Before you start: you need administrator access to the Ruijie web interface, the gateway's active WAN IP address, and the hardware serial number printed on the device label.

1 - Adding the device to the Useroam panel

Device Type: select Ruijie.
5651 Logging: tick the 5651 Logging checkbox.
Device Serial Number: [CRITICAL STEP] enter the original hardware serial number in full, exactly as printed on the label underneath the device or as shown in the web interface. The Ruijie integration will not work reliably unless this serial number is correct.
Device Address: enter the active WAN IP address the gateway uses to reach the internet.

Adding a Ruijie device in the Useroam panel

2 - Allowlist settings for trusted IPs (Allowlist → Dest. IP)

In the Ruijie management interface, go to Object > User Authentication > Authentication Settings from the top menu. Under the Allowlist tab, select the Dest. IP option and allow the Useroam Cloud server IP address (104.247.174.120) together with your hotspot service networks.

3 - Allowlist settings for trusted domains (Allowlist → URL)

Switch to the URL tab in the same menu. Add *.useroam.com to the allowlist — guests must be able to reach it before they authenticate. Also define URL rules for the messaging and operating-system captive-portal detection domains that mobile devices use to verify the hotspot network in the background (for example the WhatsApp networks).

4 - External Portal & WiFiDog authentication template

From the left-hand menu, open Authentication Template and select the External Portal tab. Enable WiFiDog Authentication, then create the template:

Version: select Wifidog V1.
Authentication Template Name: useroam
Server URL: http://104.247.174.120/ruijie-cloud/
Permission Mode: select Do Not Permit.
Sending Source: leave as Default.

5 - Authentication policy (Edit Authentication Policy)

As the final configuration step, go to Authentication Policy in the left menu and either add a new rule or edit your existing guest policy:

Name: useroam
Enabled State: set to Enable.
Src. Security Zone: select the zone your guest network belongs to (for example Guest).
Src. Address: any
Authentication Action: tick Authentication.
Authentication Template Name: select the useroam template you created in the previous step and save.

6 - Forwarding logs to Useroam (Syslog config)

So that guest internet traffic and hotspot session activity can be legally signed under Turkish Law No. 5651, the logs must be forwarded to the Useroam Cloud server. In the Ruijie management interface go to Advanced > Syslog and use the Add button to define a new syslog server:

Syslog Server Status: set to Enable.
Server IP: enter the Useroam Cloud IP address 104.247.174.120.
Server Port: 514 (the default syslog port).

Important — integration complete

That's it. Useroam Cloud Hotspot and the legal 5651 syslog integration are now fully configured on your Ruijie / Reyee gateway. Remember to update the Useroam panel whenever the device serial number or WAN IP address changes, otherwise the integration will stop working. For assistance during the process, contact our technical team at destek@useroamteknoloji.com.

For the Login with WhatsApp flow to work while the guest is still behind the captive portal (before internet access is granted), the following addresses must be allowed in your firewall or walled-garden configuration. Without these rules the WhatsApp login screen will not open and the automatic login based on delivery confirmation will not work.

Domains to allow (FQDN)

*.wa.me
*.whatsapp.com
*.whatsapp.net
g.whatsapp.net
mmg.whatsapp.net
fbsbx.com
*.useroam.com

IP addresses to allow

157.240.0.0 — Meta / Facebook network block
31.13.0.0 — Meta / Facebook network block
104.247.174.120 — Useroam panel

Note: 157.240.0.0 and 31.13.0.0 are typically /16 network blocks (Meta infrastructure); we recommend defining them as blocks in the firewall (157.240.0.0/16, 31.13.0.0/16). 104.247.174.120 is the Useroam panel IP (/32). Use the domain list if your firewall supports FQDN-based filtering; otherwise use the IP blocks.
